Pre-Drilled Panels for Door 46″ – 12mm
Price range: US$90.00 through US$180.00
12mm tempered glass panel with factory-drilled holes, designed to be installed adjacent to a glass door for mounting hinges (Hinge Kit) or latches (Latch Kit). Available in multiple heights (34″/40″/46″) and widths (4″ to 84″).
Description
Factory pre-drilling for door hardware
Our pre-drilled 12mm tempered glass panels are designed to accommodate the hardware of an adjacent glass door: hinges (Hinge Kit) on the left panel, latch (Latch Kit) on the right panel. Drilling is done at the factory, before glass tempering, ensuring structural integrity and panel safety.
Technical specifications
- Thickness: 12mm (0.47″)
- Heights available: 34″, 40″, 46″
- Widths: 4″ to 84″ in 1″ increments
- Edge finish: Polished 4 sides, rounded corners
- Drilling: Pre-tempering (maximum safety)
- Compliance: CAN/CGSB-12.1 standard
Installation
A pre-drilled panel is always installed on either side of an ENO glass door:
- Hinge-side pre-drilled panel: receives the Hinge Kit that supports the door
- Latch-side pre-drilled panel: receives the Latch Kit that locks the door
Choose your pre-drilled panel height based on your installation: 34″ for low balconies, 40″ for elevated balconies, 46″ for pool enclosures. Use our 2D Configurator to plan your door and adjacent pre-drilled panels.
Warranty and shipping
10 years against manufacturing defects (spontaneous breakage, tempering defects). Does not cover breakage caused by impact, improper installation, vandalism or abnormal use. Free shipping across Canada and the United States for orders of $999 and up.
Additional information
| Width | 24, 26, 28, 30, 32, 34, 36, 38, 40, 42, 44, 46, 48, 50, 52, 54, 56, 58, 60 |
|---|
